| Ethernet LAN data rates | 10/100/1000 Mbit/s |
|---|
| Frequency band | 2.412 - 2.484, 5.15 - 5.875 GHz |
|---|
| Networking standards | IEEE 802.11a/IEEE 802.11ac/IEEE 802.11b/IEEE 802.11g/IEEE 802.11n/IEEE 802.3af/IEEE 802.3at |
|---|
| Receiver sensitivity | 2.4GHz:
1MBit/s: -100 @ 26dBm Tx
11MBit/s: -94 @ 26dBm Tx
6MBit/s: -96 @ 26dBm Tx
54MBit/s: -78 @ 23dBm Tx
MCS0: -96 @ 26dBm Tx
MCS7: -73 @ 22dBm Tx
5GHz:
6MBit/s: -96 @ 26dBm Tx
54MBit/s: -80 @ 21dBm Tx
MCS0: -96 @ 26dBm Tx
MCS7: -75 @ 20dBm Tx
MCS9: -7 |
|---|
| Ethernet LAN (RJ-45) ports | 2 |
|---|
| Power over Ethernet (PoE) | Yes |
|---|
| Power over Ethernet (PoE) type supported | Active PoE/Passive PoE |
|---|
| Antenna features | Integrated antenna |
|---|
| Antenna gain level (max) | 2.5 dBi |
|---|
| Antenna type | Internal |
|---|
| Antennas quantity | 4 |
|---|
| PoE adapter included | Yes |
|---|
